Edible oil or cooking oil filling capping machine

FOB Reference Price:Get Latest Price
$15,000.00 - $30,000.00 / Sets | 1 Set/Sets Edible oil filling capping machine (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Packaging Type:
Barrel, Bottles, Cans, cooking oil filling capping machine
Packaging Material:
Plastic, Edible oil filling capping machine
Type:
Filling Machine
Condition:
New
Application:
Chemical, Food, Medical, oil filling capping machine
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
220V/380V
Power:
2.5KW
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
POWERRIG
Model Number:
PWG-ZX-8
Dimension(L*W*H):
2200X2100X2200MM
Weight:
500kg
Certification:
CE ISO
Name:
oil filling capping machine
Function:
Material filling
Filling material:
Food oil
Filling nozzle:
8 nozzles
Filling range:
1-5L
Production capacity:
1500-3000PBH
Material:
Stainless Steel 304/316
Filling type:
Piston filling
Package:
Standard export wooden case
Warranty:
Life Long Service
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
50 Set/Sets per Month Edible oil filling capping machine
Packaging & Delivery
Packaging Details
Edible oil filling capping machine is packed by standard export wooden box
Port
Shanghai
Lead Time :
3-5 days after received the balance payment

Edible oil or cooking oil filling capping machine

Product Description





Product Introduction:

This machine adopt PLC touch screen Siemens control,It's adopt piston filling form. The filling nozzle material tank and touches liquid part material is USU304 Teflon and POM.And it have proteation device that machine will stop and alarm when lack of materials .



Application :

Heavy sauces, salsas, salad dressings, cosmetic creams, heavy shampoo, gels, and conditioners, paste cleaners and waxes, adhesives, heavy oils and lubricants.

Main parameter
Filling head
8 heads
Votage
220V
Speed
≤3000BPH (base on 1L)

Power
2kw
Filling volume
1-5L
metering error
≤±3‰
Container minimum diameter

50mm
Air Comsumption
0.9m3/min
Working Pressure
0.6Mpa-0.7Mpa
Dimension
2440mm × 1480mm× 2610mm
Some other model for reference
Model
Filling range
Capacity
Remark
PWG-ZX-4
50-200ml/ 100-500ml/500-1000ml /1000-5000ml
1000-2000BPH

All machine voltage according to customer requirements to make
PWG-ZX-8
50-200ml/ 100-500ml/500-1000ml /1000-5000ml
2000-3000BPH
PWG-ZX-16
50-200ml/ 100-500ml/500-1000ml /1000-5000ml
3000-4000 BPH
PWG-ZX-20
50-200ml/ 100-500ml/500-1000ml /1000-5000ml
4000-5000BPH
All machine filling nozzle quantity could be custom
PWG-CZ-4
5-25L / 8-30L
250-300BPH
PWG-CZ-8
5-25L / 8-30L
300-450BPH
