Rotary mosquito liquid spray filling machine for Mosquito Repellant Filling Machines

FOB Reference Price:Get Latest Price
$9,000.00 - $33,000.00 / Sets | 1 Set/Sets (Min. Order)
Power:
370W
Model Number:
Powerrig-L45
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 Year
Packaging Type:
Bottles
Packaging Material:
Wood
Type:
Filling Machine
Applicable Industries:
chemical industry
Condition:
New
Application:
Medical, Chemical
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
110v/220v/380v can customize
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
powerrig
Dimension(L*W*H):
1800*1000*1500mm
Weight:
600kg
Certification:
CE ISO
After-sales Service Provided:
Online support, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service
Name:
spray bottle filling machine
Filling material:
Mosquito Repellant /mosquito spray liquid
Usage:
spray bottle filling and capping
filling method:
vacuum filling machine
Filling volume:
25-250ML. 50-500ML. filling volume can customize
Filling speed:
30-50 bottles per min
Filling accuracy:
+/- 1mm
Controller:
PLC+ touch screen
Air pressure:
pressure≥4Kg/cm2,
Flow quantity:
0.11m3/min
Supply Ability
Supply Ability:
15 Set/Sets per Month
Packaging & Delivery
Packaging Details
1.Export free fumigating wooden case 2.One set in one case with film wrapped
Port
shanghai/ningbo poat
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Video Description
Trade Insurance
Suitable Package
Product Description
Parameter of  mosquito liquid spray bottle filling capping machine
Filling method
3 piece Three heads all is vacuum filling
Vacuum sucition back filling method
Filling Speed
30- 640 bottlse per minute
 Filling accuracy
+/- 1mm   Filling volume from 5ml -100ml (customize)
Air pressure
pressure≥4Kg/cm2,
Power
3.7KW

Rotary mosquito liquid spray filling machine for Mosquito Repellant Filling Machines

This Rotary mosquito liquid spray filling machine for Mosquito Repellant Filling Machines is auto negative pressure vacuum filling, auto bottle detecting( no bottle no filling ), filling for three times. Auto dropping of crimp pump cap, circulation of spray bottles' die set, It is wide adaptability which can meet to requirements of different dimension and filling volume of containers.
This filling machine can be divided into automatic bottles feeding (Also can use choose manual load bottle) automatic filling, automatic pump cap capping head, pre-capping head for regulate and tighten up pump cap head and automatic capping etc.
The filling separate 3 times filling ,capping separate 2 times capping, Ensure the filling accuracy higher and filling speed faster.



Work princinple

Put the bottles into the feeding conveyor, let them enter the filling machine in order
The exam sensor starts to exam if there is bottle on this station. Then deliver the exam signal to the inner control system, to control no bottle, no filling
If the sensor exams there are bottles, then the filling machine starts to fill.
The bottles after filling enter into the automatic caps dropping station through the rotary table.
The bottles after dropping caps enter into automatic capping station.

Detailed images

Vacumm suction filling pump  with pisston cylinder

Our machine filling head have a suction liquid return back function,filling nozzle connect with suction back cylinder

When the filling liquid reach we set up fix Level, the overage liquid will be suctioned back,
Because when inner pipe filling material reach the fix level of outside jacket.

Vacuum filling nozzle

The outside jacket connect with vacuum suction air pipe. The inner jacket connect with filling perfume material pipe.
Outside jacket connect with Negative pressure suction air pipe(There are have a vacuum generator connect with the air pipe) .
Before filling perfume, outside jacket will sealing the bottle mouth first and suction the air from bottle

Spray bottle load into conveyor blet

Use conveyor belt loading glass perfume bottle into rotary turn chuck table.

Spray cap screw Capping heads or crimping head

Cans customize different type capping head or crimping head according to customer's different cap

If your caps is plastic cap with inner plug can use above picture show capping head, if your caps is metacl spray cap .can customize crimping cap head for metacl cap or spray cap,

Spary cap insert loading station

Spray cap through vibrating plate sort of , then through load guide send to loading station, air cylinder push spray cap into bottle.

 Righting up cap station

Before screw capping the caps , add a righting up the cap, usded to righting up the cap station in the bottle mouth.

Spray caps sort of vibrating plate

Used to sort of the spray caps automatically .

Spray caps loading guide

Used to loading spray caps into insert spray cap station.

All filling ,crimping capping station in one chuck

1. Vacuum filling head (3 pieces), 3 times Quantitative filling.
2. Inert pump cap station( connect with send pump cap guide and vibrating plate)
3. Pre-tighten up and regulate position of pump cap head
4. Capping pump cap head
5. Load outside plastic cup head
6. Press outside plastic cup head
(Capping method will customize according to different customer caps)

Touch sreen operation

 Touch screen control panel

All operations all can finish in one touch screen
Every filling nozzle's filling time, filling speed , filling volume can adjust separately.
And bottle filling amounts also can adjust as need.
Machine running speed ,filling volume ,capacitu all can set up.

Rotary mosquito liquid spray filling machine for Mosquito Repellant Filling Machines can totally customize according to customer's different perfume bottle and caps
According to customer's requirements, customize whole production ,included the filling machine, capping machine , labeling machine , sealing machine and bottle connection table.

If you have any questions or requirements about this Rotary mosquito liquid spray filling machine for Mosquito Repellant Filling Machines   ,please kinding send your inquiry:

Customize service

If you need the whole produdction line of the Rotary mosquito liquid spray filling machine for Mosquito Repellant Filling Machines  , we also can help you match the labeling machine after filling and capping machine
The bottle Ultrasonic washing machine and the bottle feeder unscrabler table or box type bottle unscrabler used to sort of bottle and send bottle into filling capping machine automatically, need match which type labeling machine or which type
bottle feeder machine need customize according to customize different bottles.

1. Can help customer find raw material, package bottle, offer whole line serivce
2. Offer customize serivce, according to customer different tube customize machine
3. Offer Machine layout design according to customer's site size
4. Offer engineer Go abroad to install and trainning
5. Whole-lifer after sale serivce
Packing & Delivery
Packaging use export wooden case pack
Size
950*950* 1300mm
Weight
650kg
Packing detailed
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Our Company
FAQ

Q:How Can I get a detailed quotation of Rotary mosquito liquid spray filling machine for Mosquito Repellant Filling Machines  from you?
Just send us inquiry through this web page is ok. I will reply your any question within in 6 hours.

Q:Can your company able to offer 2 years gurantee?
Yes it's no problem for our company. During the warranty, if you need any spare parts, we will delivery it to you in DHL for free.

Q:Do you offer a free set of replacement parts for parts that commonly wear out quickly?
All spare parts are always avaliable for delivery. Above 90% spare parts are made by ourselves. Because we have our own processing center, so we can supply at anytime.

Q:What is the whole production line?Can i connect labeling machine ,bottle feeder with filling machine in whole line?
I do not know how many meters of conveyors are involved so can not determine the over-all size of the line with all of its components?
We can help you match pipe and pump to transfer material form raw material tank to filling directly., so it can be totally auatomaticlly.We will design and make a layout plan according to customer's factory floor plan.

Q:What is the cost to send installation/training staff? How many staff do you need to send?
Whole installation/traning process needs 2peoples. Around 10days. Client needs to provide us round-air ticket, visa fee, local transpotation, accomodation, food, and 80USD/day/person.

If you have any questions or requirements about this Rotary mosquito liquid spray filling machine for Mosquito Repellant Filling Machines   from you ,please kinding send your inquiry:
